NKM G / NKP G

TECHNICAL DATA

Rotation speed: 970-1450-2900 1/min
Operation range: from 1 to 1100 m3/h with a head up to 158 m
Pumped liquid: without solid or abrasive substances, not viscous, not aggressive, not crystallised and chemically neutral, close to water.
Liquid temperature range: from -25 °C to +140 °C
Maximum ambient temperature: + 40 °C
Maximum working pressure: 16 bar – 1600 kPa
Flanging: PN 16 UNI/EN 1092-1
PN 10 UNI/EN 1092-1 for DN 250
Installation: normally horizontal or vertical provided the motor is always above the pump
Special version on request: pumps for liquids other than water.
